DIPLOMA IN CIVIL ENGINEERING

STRUCTURAL DYNAMICS LAB

22 Computer Systems

AUTO CAD LAB

computer system 25 || 24 port switch, network switch 1 || network switch rack 1 || patch panel 1 || bently academic perpetual offering solution contain 5CD's 1 || bently academic perpetual offering solution 1

HYDRAULICS LAB

Bernoulli's apparatus 1 || losses in pipe apparatus 1 || meta-centric height of ship model 1 || centrifugal pump set rig 1 || pressure measurement apparatus 1 || reciprocating pump set rig 1 || pelton wheel turbine 1 || U-tube manometer 1 || Reynold's apparatus 1 || orifice & mouthpiece apparatus 1 || notch apparatus 1 || impact of jet apparatus 1 || venturimeter 1 || orificemeter 1

GEOTECHNICAL ENGINEERING LAB

pycnometer 3 || triaxial shear test machine 1 || direct shear test machine 1 || unconfined compression test machine 1 || consolidation test apparatus 1 || standard proctor test apparatus 1 || permeability test apparatus 1 || core cutter 2 || shrinkage limit test apparatus 3

STRENGTH OF MATERIALS LAB

mechanical extensometer 1 || universal testing machine 1 || compression testing machine 1 || rockwell cum brinell hardness 1 || impact testing machine 1 || shear test attachment 1 || tile flexural test attachment 1

TRANSPORTATION ENGINEERING LAB

TRANSPORTATION ENGINEERING LAB

CONCRETE TECHNOLOGY LAB

vibration machine 1 || air permeability apparatus 1 || vicat apparatus 1 || le-chatelier apparatus 1 || slump cone test apparatus 1 || compaction factor test apparatus 1

ENVIRONMENTAL ENGINEERING LAB

micro controller based visible spectrometer 1 || water analyzer 1 || BOD incubator 1 || serological water bath 1 || muffle furnace 1 || weighing balance 2 || rectangular hot plate 1 || rectangular hot plate with PID control 1 || BOD analyzer 1 || COD analyzer 1 || COD digester 1 || hot air oven 1 || Imhoff cone 1

SURVEYING LAB

dumpy level 2 || auto level 2 || theodolite 2 || chain 6 || total station 1 || levelling staff 5 || mechanical planimeter 2 || nautical sextant 1 || prismatic compass 2 || surveyor's compass 1 || optical square 4

ENGINEERING GEOLOGY LAB

mineral samples 40 || igneous rocks 25 || sedimentary rocks 25 || metamorphic rocks 25 || mohr's scale of hardness 5
